    90 Degree Single Port Shielded RJ45 Ethernet Connector With LEDs Network Port Socket

    Ask Lasest Price
    Brand Name : PHCONN
    Model Number : 1051-208004
    Certification : ISO:9001;ISO:14001
    Price : $0.50-$1.00
    Payment Terms : L/C, T/T
    Supply Ability : 5,000,000 PCS / Month
    Delivery Time : 7 - 10 Work Days
    • Product Details
    • Company Profile

    90 Degree Single Port Shielded RJ45 Ethernet Connector With LEDs Network Port Socket

    RJ45 Modular Jack with LEDs(YG),Offset Jack Shielded Mini RJ45 Connector for panel Mount

    MECHANICAL:


    1. HOUSING MATERIAL:glass-filled polyester(UL94V-0).

    2. CONTACT MATERIAL:phosphor bronze T=0.46mm (C5 100).

    3. PLATING: gold plating over nickel.

    4. DURABILITY:750 cycles min.

    5. PCB RETENTION PRE-SOLDER:1 LB min.

    6. PCB RETENTION POST-SOLDER:10 LB min.

    Product Information

    CategoriesConnectors, Interconnects
    Modular Connectors
    Application-LANETHERNET(non-POE)
    Connector TypeRJ45
    Number of Positions/Contacts8p8c
    Number of Ports1x1
    Mounting TypeThrough Hole
    Orientation90° Angle (Right)
    TerminationSolder
    Height Above Board0.537" (13.65mm)
    LED ColorGreen - Yellow
    ShieldingShielded, EMI Finger
    FeaturesBoard Guide
    Tab DirectionUp
    Contact MaterialPhosphor Bronze
    PackagingTray
    Operating Temperature0°C ~ 70°C
    Contact Material Plating ThicknessGold 6.00µin/15.00µin/30.00µin/50.00µin
    Shield MaterialBrass
    Housing MaterialThermoplastic
    RoHS CompliantYES-RoHS-5 WIth Lead in Solder Exemption

    ELECTRICAL:


    1. VOLTAGE RATING:125 VAC RMS.

    2. CURRENT RATING:1.5 AMP.

    3. CONTACT RESISTANCE:50 milliohms max.

    4. INSULATION RESISTANCE:500 megohms min @ 500V DC.

    5. DIELECTRIC WITHSTANDING

    RESISTANCE:1000V AC RMS 50Hz. 1min.


    ENVIRONMENTAL:


    1. STORAGE:-40℃ TO +85℃.

    2. OPERATION:0℃ TO 70℃

    3. WAVE SOLDER TEMPERATURE:230-250℃(5-10 seconds)

    MATES WITH MODULAR PLUG CONFORMING TO FCC PART F.


    Drawing:


    Production&Testing

    PHC have more than 30 units automation equipments to product as possible
    PHC Every Magnetic RJ45 tested 3times (not just batch tested)
    PHC Every SMT part used Automation testing and packing.



    Lead Time

    With large Popularity of 450 Workers distributed in 4 subsidiary corporations, PHC can offer the fastest
    Lead time,and the particular case is according to the situation.


    Case.1Stock25%
    Case.23-4 Weeks70%
    Case.35-6 Weeks5%



    Service

    PHC Offer good pre-sales & after-sales service &Strong technical support

    • New Project: Strong technical and ideal support your new design
    • Existing projects: Try to help customer to save the cost to offer the good quality product and save
    • time.
    • Free Samples:3-5 PCS of each part number
    • Shipping Fee :We can get 80% off from DHL/UPS/TNT/FedEx, keeping safe and fast.
    • Customer complaint:24-48 hours reply 8D report
    • Warranty : 24 months ( Merchandise are promised to be promptly returned, replacement,,or repair
    • kits if customers are not satisfied)
    Why Choose Us

    What can we do for you?

    1. We can offer free samples.

    2.Various operation force, height, and color for your choice.

    3. large quantity discount


    Why us?


    1. Excellent quality with competitive price

    We are a manufacturer making RJ45 for more than 15 years.

    2.Quality guaranty

    Check quality one by one before shipping, We have a good quality-control team and

    precision testing machine to control the quality seriously

    3. Customize acceptable

    according to your design to produce a quality product.
